E533
Compactfloor
Compact floor manifold arrangement in a cabinet
Manifold with 2.5 l/min flow meters, Mechanical temperature control, Isolating valve, High-efficency pump, Actuating drive for heating circuit control and electric wiring centre, two radiator connections.
Preassembled in distributor cabinet made of galvanized steel sheet, front frame and door powder coated, white (RAL 9010).
Adjustable installation depth and cabinet height with removable pipe rail tracks.
Radiator connection is not temperature controlled.
Product List
| Code | Qty | Product | Description |
|
Order |
|---|---|---|---|---|---|
| 3E53303 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53304 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53305 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53306 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53307 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53308 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53309 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53310 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53311 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53312 | Compactfloor UFH & RAD | Right hand connections |
|
|
|
| 3E53313 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53314 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53315 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53316 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53317 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53318 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53319 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53320 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53321 | Compactfloor UFH & RAD | Left hand connections |
|
|
|
| 3E53322 | Compactfloor UFH & RAD | Left hand connections |
|
|
